Aluminium windows
and doors

Profile name: Reynaers CS 59PA (Concept System 59 'Parallel' window/door)
Non-insulated system
Frame width: 59 mm
Glazing thickness: 4 to 35 mm
Acoustic performance: Rw (C;Ctr) = 36 (-1;-3) dB / 44 (-2;-4) dB, depends on the glazing type
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
Anti-burglar: WK 2 (European standards ENV 1627 - 630) (ENV 1627, ENV 1630)
Water tightness: up to 600 Pa (class 9A) (EN 1027, EN 12208)
Wind load resistance: up to 2000 Pa (class 5) (EN 12211, EN 12210)
CS 59Pa can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories
This system is ideal for out-door applications in warm climates but it can also be used for the partitioning of indoor office spaces
Any RAL colour

Profile name: Reynaers CS 68 (Concept System 68 window/door)
Insulated system
Frame width: 68 mm
Glazing thickness: 4 to 54 mm
Acoustic performance: Rw (C;Ctr) = 37 (-1;-4) dB / 44 (-2;-5) dB, depends on the glazing type (EN ISO 140-3, EN ISO 717-1)
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
nti-burglar: WK 2 (windows and doors) (European standard ENV 1627 – ENV 1630), WK 3 (windows-doors, doors and fixed windows)
Thermal insulation: Uf – between 1.8 W/m2K and 2.9 W/m2K , depending on the frame/vent combination
Water tightness: up to 1200 Pa (class E1200) (EN 1027, EN 12208)
Wind load resistance: up to 2000 Pa (class 5) (EN 12211, EN 12210)
CS 68 can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories
CS 68 is a thermally improved system that boasts the optimum combination of high insulation level and optimum safety
Double butt strips between the frame and vent and lowered drainage ensure superior wind and water tightness
Any RAL colour

Profile name: Reynaers CS 77 (Concept System 77 window/door)
Insulated system
Frame width: 77 mm
Glazing thickness: 4 to 54 mm
Acoustic performance: Rw (C;Ctr) = 36 (-1;-4) dB / 42 (-2;-4) dB, depends on the glazing type (EN ISO 140-3, EN ISO 717-1)
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
Anti-burglar: WK 2 (windows and doors) (European standard ENV 1627 – ENV 1630), WK 3 (windows-doors, doors and fixed windows)
Thermal insulation: Uf-value down to 1.2 W/m²K depending on the frame/vent combination and the glass thickness
Water tightness: up to 900 Pa (class E900) (EN 1027, EN 12208)
Wind load resistance: up to 2000 Pa (class 5) (EN 12211, EN 12210)
CS 77 can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories
CS 77 is a thermally improved system for windows and doors that boasts the optimum combination of safety and comfort
Thermal insulation is guaranteed because of fiberglass reinforced polyamide strips with ribs and/or hollow chambers
Double butt strips between the frame and vent and lowered drainage ensure superior wind and water tightness
Any RAL colour

Profile name: Reynaers ES 45PA (Eco System 45 'Parallel' window/door)
Non-insulated system
Frame width: 45 mm
Glazing thickness: 4 to 42 mm
Acoustic performance: Rw (C; Ctr) ≤ 39 (-1; -3) dB, depends on the glazing type (EN ISO 140-3, EN ISO 717-1)
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
Anti-burglar: WK 2 (European standards ENV 1627 - 630) (ENV 1627, ENV 1630)
Water tightness: up to 600 Pa (class 9A) (EN 1027, EN 12208)
Wind load resistance: up to 2000 Pa (class 5) (EN 12211, EN 12210)
ES 45Pa can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories
Any RAL colour

Profile name: SlimLine 68 window
Insulated system
Frame width: 68 mm
Glazing thickness: 26 to 43 mm
Acoustic performance: Rw (C; Ctr) = 36 (-1; -5) dB / 47 (-2; -7) dB, depending on glazing type (EN ISO 140-3, EN ISO 717-1)
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
Anti-burglar: PAS 24
Thermal insulation:
Uf-value down to 2.6 W/m²K depending on the frame/vent combination and the glass thickness
Uw ≥ than 1.4 W/m²K for a standard window section
Water tightness: Up to 1050 Pa (class E1050)
Wind load resistance: Up to 2400 Pa (class E2400)
SlimLine 68 can be realised with all types of opening windows with an extensive choice of accessories
SlimLine 68 window system is specifically designed to meet the demand for an outward-opening window with very slim profiles
Particularly suited to use in residential properties, this window maximises the glass area to let in lots of natural daylight
Any RAL colour

Profile name: Reynaers MasterLine 8 (MasterLine 8 window/door)
Superior insulation system with universal solutions Frame width: 87 mm
Glazing thickness: 4 to 62 mm
Acoustic performance: Rw (C;Ctr) = 36 (-1;-4) dB / 44 (0;-2) dB, depends on the glazing type (EN ISO 140-3, EN ISO 717-1)
Air tightness max. test pressure: up to 600 Pa (class 4) (EN 1026, EN 12207)
Anti-burglar: WK 2 (windows and doors) (European standard ENV 1627 – ENV 1630)
Thermal insulation: Uf - value down to 1.2 W/m²K depending on the frame/vent combination and the glass thickness
Water tightness: up to 900 Pa (class E900) (EN 1027, EN 12208)
Wind load resistance: up to 2000 Pa (class 5) (EN 12211, EN 12210)
MasterLine 8 can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories
MasterLine 8 features 3 different levels of insulation for high insulated, low energy and even passive houses
MasterLine 8 is a unique window system that combines countless design opportunities with first in class performance in terms of thermal insulation, air-and water-tightness, and production speed.
MasterLine 8 doors offer a wide range of highly insulated and robust flush doors, which meets the modern requirements with regard to safety, thermal insulation and stability, allowing the creation of large entrance doors.
Any RAL colour
